SMART-51 laminating printer is a good option for printing and laminating in one step to procedure high-security ling-life ID cards with customizable security patch films. With IDP patented Direct lamination technology, SMART-51L is the industry’s fastest “ready to print” laminator. In only 8 seconds, IDP laminator is ready to print and laminate your highly secure cards.
| Category | Specification |
|---|---|
| Printing | Single-Sided / Double-Sided Printing |
| Print Type | Direct Dye-Sublimation |
| Print Area | Edge-to-Edge |
| Resolution | 300 dpi (Color & Mono), 600 & 1200 dpi (Mono Only) |
| Dual-Side Printing | Optional (with Flipper) |
| Monochrome Speed | 5 sec/card (720 cards/hour) |
| YMCKO Speed | Max. 17 sec/card (156 cards/hour) |
| Card Feeding | Automatic |
| Card Size | ISO CR80 or ISO CR79 (Factory Option) |
| Card Thickness | 0.38 mm (15 mil) – 1.0 mm (40 mil) |
| Card Type | PVC, PET, Composite PVC |
| Input Hopper | 100 / 200 Cards |
| Output Hopper | 40 / 100 Cards |
| Memory | 64 MB RAM |
| Interface | 1 LED Button |
| Supported Platforms | Windows 7/8/10, Mac OS, Linux |
| Communication | USB, Ethernet, Wi-Fi (Optional) |
| Power Supply | AC 100–220V, 50–60Hz |
| Power Consumption | 48W |
| Operating Temperature | 15–35°C |
| Humidity | 35–70% |
| Security | Physical Lock for Input Hopper & Ribbon (Optional), Kensington Lock (Optional) |
| Dimensions | 165 (W) × 390 (L) × 210 (H) mm |
| Dimensions (Inches) | 6.5 (W) × 15.4 (L) × 8.3 (H) in |
| Weight | 4.5 kg / 10 lbs |
| Magnetic Encoding | ISO 7811 Track I, II, III Read/Write, HiCo/LoCo, JIS II |
| Contact Encoding | ISO 7816 A/B/C, ISO 7816-1/2/3/4 Microprocessor Cards |
| Contactless Encoding | ISO 14443 Type A/B, MIFARE, DESFire, iCLASS, NFC (ISO 18092), Felica |
| Certifications | CB, CE, FCC, KC, CCC |
